The question behind the tool
Most Linux users treat process memory as a single number. Tools such as top, ps, or pmap report RSS or VSZ, and the conversation often stops there. Underneath those numbers is a virtual address space composed of many distinct mappings, each with its own permissions, backing, and residency characteristics.
memmap was built to make that structure visible. It is a C utility that reads the kernel’s process interfaces directly—primarily /proc/<PID>/maps, /proc/<PID>/smaps, and /proc/<PID>/comm—parses them into a structured model, classifies the mappings, and presents the results as tables, summaries, or JSON.
The project deliberately stays close to the operating system. It does not wrap another command; it observes the interfaces the kernel already exposes.
Architecture
The program is organized as a pipeline of clear responsibilities:
CLI → process collection → memory model → analysis → display
Collection reads /proc. Parsing turns the text into C structures. Analysis classifies mappings and computes aggregates. Display formats the same model in multiple ways. Main orchestration stays thin and does not itself parse /proc.
Key source modules:
cli.c/cli.h— argument parsing and option storageproc.c— existence checks and opening of/proc/<PID>filesmaps.c— line-oriented parsing of/proc/<PID>/mapssmaps.c— enrichment with per-mapping statisticsmemory.c— dynamic array of mappings and ownershipanalyzer.c— classification, filtering, sorting, summarydisplay.c— table, summary, and JSON outpututil.c— PID validation and helpers
The central data structures are struct memory_mapping (one region) and struct memory_map (the complete process view). Ownership is explicit: the map owns the array of mappings, every pathname string, and the process command name. memory_map_free() releases them.
Mappings are stored in a dynamically growing array that starts at capacity 64 and doubles on exhaustion. This is ordinary amortized growth; processes have highly variable numbers of mappings.
Reading the kernel interfaces
`/proc//maps`
Each line describes a virtual memory region roughly as:
start-end perms offset device inode pathname
The parser extracts start and end addresses, permissions, offset, device, inode, and pathname, then computes size as end - start. Because pathnames can be long and lines variable-length, the code uses getline() (with _POSIX_C_SOURCE 200809L) rather than a fixed buffer. The return value is correctly typed as ssize_t so that the end-of-file / error sentinel -1 can be represented.
Parsing is deliberately bounded:
n = sscanf(line, "%lx-%lx %4s %lx %31s %lu %4095[^\n]",
&start, &end, perms, &offset, device, &inode, pathbuf);
Field widths reduce the chance of overflowing fixed buffers when converting the kernel’s text.
`/proc//smaps`
smaps supplies richer statistics per mapping: Size, Rss, Pss, Shared_Clean, Shared_Dirty, Private_Clean, Private_Dirty, Anonymous, Swap, and others. Values arrive in kilobytes and are converted to bytes for internal consistency.
smaps is treated as best-effort enrichment. If it is unavailable (permission, disappearance of the process, etc.), the mappings obtained from maps are still retained. The core purpose of the tool is the mapping layout itself; detailed residency numbers are an enhancement.
Process command name
/proc/<PID>/comm supplies the short name. The trailing newline is stripped and a copy is stored under the ownership of the memory map.
Classification, filtering, and accounting
Raw kernel text is turned into semantic categories after parsing:
[heap]→ heap[stack(including thread forms such as[stack:1234]) → stack[vdso],[vvar],[vsyscall]→ corresponding special regions- no pathname → anonymous
- paths containing
.so,ld-linux,ld-musl→ library - absolute path with execute permission → executable
- other absolute paths → file-backed
Classification lives in the analyzer, not the parser. The parser answers “what did the kernel say?”; the analyzer answers “what does that mean?”
Filters (--libraries, --heap, --stack, --exec, --write, --shared, --private, --anonymous) are applied to individual mappings via a single predicate. Display never hard-codes the meaning of those categories.
Sorting uses the standard library qsort(). Supported keys are size, RSS, PSS (descending) and start address (ascending). The engineering value of the project is Linux memory inspection, not a custom sort implementation.
Summary analysis computes aggregates over the structured model:
- VSS — sum of mapping sizes (virtual address space)
- RSS — resident pages attributed to the mappings
- PSS — proportional share of shared pages
- anonymous vs file-backed RSS
- executable, writable, shared, and private sizes
Because the analysis operates on the in-memory model rather than re-reading /proc, it can be exercised with synthetic mappings in unit tests.
Demand paging in practice
Two controlled experiments demonstrate why virtual size and resident size diverge.
Both programs create an approximately 100 MB anonymous mapping with mmap(MAP_PRIVATE | MAP_ANONYMOUS, PROT_READ | PROT_WRITE).
The untouched variant never writes to the pages. Observed summary:
Virtual Memory (mapped): 102.71 MB
Resident (RSS): 1.84 MB
Proportional (PSS): 155.0 KB
Anonymous (RSS): 56.0 KB
The touched variant writes one byte every 4096 bytes (the observed page size from sysconf(_SC_PAGESIZE)). Observed summary:
Virtual Memory (mapped): 102.71 MB
Resident (RSS): 101.84 MB
Proportional (PSS): 100.15 MB
Anonymous (RSS): 100.05 MB
Virtual size is essentially identical; residency changes by nearly two orders of magnitude. Linux demand-paging establishes physical backing only when a page is first accessed. An mmap that is never touched therefore consumes little resident memory. Touching every page forces the page faults that populate the resident set.
Filtering to anonymous mappings on the touched process shows a single large writable anonymous region of approximately 100 MB with matching RSS—exactly the mapping created by the experiment.
An earlier attempt that used malloc without touching the memory produced unexpectedly small mappings. The compiler was free to eliminate an allocation whose result was never observed. Switching to an explicit mmap made the virtual-memory behavior deterministic and visible.
Operational behavior
Watch mode repeatedly collects, analyzes, and displays, sleeping for a configurable interval (default 1 s). SIGINT and SIGTERM set a simple flag; the main loop exits cleanly rather than performing complex work inside the signal handler.
Processes can disappear between the existence check and the open of maps or smaps. The code treats ENOENT as “process exited during inspection.” Permission failures surface as EACCES rather than opaque errors. /proc is a live view of the system; races are expected.
PID validation rejects empty strings, non-numeric input, zero, negatives, overflow, and trailing characters. It uses strtoul rather than atoi so that conversion errors are detectable.
Build and quality constraints
The normal build uses:
-std=c11 -Wall -Wextra -Wpedantic -O2 -g
A debug configuration adds -O0, AddressSanitizer, and UndefinedBehaviorSanitizer. Object files live under build/. A clean rebuild is the expected workflow.
Several correctness issues encountered during development are worth recording because they are typical of systems code:
- Feature-test macros are required for
getline. getlinereturnsssize_t; treating the result assize_tis wrong.- Format strings must bound every conversion; a suppressed assignment (
%*) silently drops pathnames and breaks classification. - Partial parse success can look plausible while semantic fields are wrong. Parser tests must check every field.
Scope and limitations
memmap is intentionally Linux-specific and observational. It does not ptrace, inject code, modify process memory, or attempt to replace htop, pmap, perf, or a debugger. Its job is to expose the structure that /proc already makes available.
Known limitations include incomplete JSON string escaping, heuristic library detection, sequential matching of smaps entries to maps entries, and the need for a fuller automated test suite. Future work can tighten those areas without expanding the core mission.
What the project demonstrates
A process does not simply “have memory.” It has a virtual address space composed of mappings. Those mappings carry permissions, backing (anonymous or file), sharing semantics, and residency. Linux surfaces much of that information through a virtual filesystem. memmap turns the text into a structured, filterable, sortable, machine-readable model and, through controlled experiments, makes demand paging observable.
The resulting artifact is small enough to understand completely yet touches kernel interfaces, virtual memory accounting, C systems programming, and the construction of observability tools. That combination is the point of the project.
